Universal Vibration System - ELSHADDAI –
DYN – 001
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
The apparatus is designed to help in conducting various experiments to illustrate and verify the principles and relations involved in the study of vibrations. Following experiments can be performed with this unit.
GYROSCOPE - ELSHADDAI –
DYN – 002
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
It is designed to verify the gyroscopic rules of a plane rotating disc The set up consists of heavy stainless steel disc mounted on a horizontal shaft, rotated by a variable speed motor. Rotor disc can be move about three axis.
STATIC AND DYNAMIC BALANCING MACHINE - ELSHADDAI – DYN – 003
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
This equipment is designed for carrying out the experiment for balancing a rotation mass system. The apparatus consists of four circular discs mounted on a shaft. The discs are grooved for the attachment of weights at a specific radius. The block are clamped on shaft is rotated by a motor to check dynamic balance of the system.
DYNAMIC BALANCING MACHINE - ELSHADDAI – DYN – 004
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
A Dynamic Balancing Machine is a precision instrument used to measure and correct imbalances in rotating components such as shafts, wheels, or rotors. Here’s a brief overview:It detects and corrects rotational imbalances to enhance the performance and longevity of rotating machinery, reduce noise, and prevent mechanical failures.
WHIRLING OF SHAFT - ELSHADDAI –
DYN – 005
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
A Dynamic Balancing Machine is a precision instrument used to measure and correct imbalances in rotating components such as shafts, wheels, or rotors. Here’s a brief overview:It detects and corrects rotational imbalances to enhance the performance and longevity of rotating machinery, reduce noise, and prevent mechanical failures.
GOVERNOR - ELSHADDAI –
DYN – 006
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
To study the determination of characteristics curves of radius of rotation against controlling force (Actual & Theoretical) for all governors. The set-up is designed to study the working of different governors normally used to control the speed. It consists of a main spindle, mounted vertically on the base plate.
CAM ANALYSER - ELSHADDAI –
DYN – 007
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
The apparatus is designed to study the cam profiles and performance of cam and follower system. A shaft supported by ball bearings upon which three different types of cams can be mounted.
EPICYCLIC GEAR TRAIN APPARATUS - ELSHADDAI –
DYN – 008
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
Gear Train is any combination of gear wheels by which motion is transmitted from one shaft to another shaft. In epicyclic gear trains, the axes of shafts on which the gears are mounted may move relative to a fixed axis.
It is a motorized unit consisting of a SUN gear mounted on input shaft. Two plane gear meshes with the annular gear. These planet gears are mounted on a common arm to which output shaft is fitted. Loading arrangement is provided for loading the system and to measure holding torque.
PIN AND DISC WEAR APPARATUS - ELSHADDAI –
DYN – 009
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
The Pin And Disc wear Apparatus consists of a steel disc whose top surface is case hardened and ground. The disc is rotated by a single ph. Induction motor at 3 different speeds. The test pin is inserted in a pin guide so that one end of pin touches the rotating disc. The pin guide is mounted on a cantilever to which spring balance is attached.
The pin is inserted in the pin guide. The disc is set to rotate at the required speed. The required load is put over the pin and wear of the pin is measured for a time interval of 5 minutes. Different materials can be tested at different speeds, bearing pressures and either lubricated or non lubricated form.
JOURNAL BEARING APPARATUS - ELSHADDAI –
DYN – 010
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
Journal Bearing Apparatus for investigating the distribution of pressure in slide bearings illustrates the principle of hydrodynamic lubrication. The distribution of pressure and the carrying capacity can be determined on a sliding bearing model at different bearing loads and speeds. The sliding bearing consists of a bearing journal driven by an electrical motor and the freely moving bearing housing. The bearing is loaded with different, interchangeable weights. The setup contains manometer tubes, dc motor, dc drive to control speed, set of weights, oil tank, Journal bearing along with the shaft.
FREE & FORCED VIBRATION APPARATUS - ELSHADDAI –DYN – 011
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
The set-up consists of a Frame & Stand with Spring Steel Beam. An Exciter unit with 2 discs and small mass which acts as eccentric weight,with speed controller, speed indicator and sensor is provided. Experiments:-To study damped natural vibrations of beam in Cantilever beam position and to plot a graph of Amplitude vs. Frequency.
TWO ROTOR SYSTEM - ELSHADDAI –
DYN – 012
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
A two-rotor system is a setup involving two rotating masses (rotors) mounted on a common shaft or connected by a coupling. It is a simplified model used to study the dynamics of coupled rotating systems, such as those found in turbines, compressors, or certain machine tools.
TURN TABLE APPARATUS - ELSHADDAI –
DYN – 013
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
A Turn Table Apparatus is a specialized machine used for balancing rotors and assemblies in dynamic balancing processes. It allows the precise measurement and correction of imbalances in rotating parts by providing a controlled and adjustable platform on which the components can be rotated and analyzed.
TRANSVERSE VIBRATION COMBINED SETUP - ELSHADDAI –DYN – 014
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
A Transverse Vibration Combined Setup is a laboratory or testing apparatus designed to study the transverse (lateral) vibrations of a system, typically involving beams or shafts. This setup allows for the observation, measurement, and analysis of vibratory behaviour under various conditions and loads, making it essential for understanding dynamic properties and structural integrity.
TORSIONAL VIBRATION SETUP - ELSHADDAI –
DYN – 015
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
A Torsional Vibration Setup is a laboratory apparatus designed to study torsional (twisting) vibrations in rotating systems such as shafts, flywheels, or couplings. It simulates conditions under which torsional vibrations occur and measures their effects, providing insights into the dynamic behavior of the system.
VIBRATING TABLE - ELSHADDAI –
DYN – 016
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
To determine transmissibility of forced vibrations and to analyze all types of Vibrations with its frequency and amplitude Motor:1/6 HP, Speed:2800 Rpm With Digital Rpm Indicator, Dimension: L B H 1000 X 700 X 950 Approx, Overall Weight:60 Kg (Approx)
Bending Testing Equipment - ELSHADDAI –
DYN – 017
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
Bending testing equipment is used to evaluate the mechanical properties of materials by subjecting them to bending forces. This equipment typically includes:
Bending Fixture: A fixture designed to hold the specimen securely and apply the bending load.
Loading Mechanism: This can be a hydraulic system, motorized actuator, or manual mechanism to apply controlled bending forces to the specimen.
Unsymmetrical Bending Apparatus - ELSHADDAI –
DYN – 018
Manufacturer, Supplier, and Exporter of Science Instruments by ELSHADDAI ENGINEERING EQUIPMENTS
An unsymmetrical bending apparatus is specifically designed for testing materials under conditions where the bending load does not act symmetrically with respect to the cross-section of the specimen. This type of testing setup is used to simulate real-world scenarios where materials may experience off-center or asymmetric loading, which can affect their bending behavior and strength.
